NetScreen-5000 Modules
NetScreen-5000 Series
11
The 5000-2XGE SPM
The 5000-2XGE SPM provides two 10-Gigabit mini-GBIC Ethernet ports using
hot-swappable transceivers. The 5000-2XGE SPM delivers up to 10 Gbps of firewall and
up to 5 Gbps of VPN capacity. This SPM cannot be mixed with the 5000-8G or 5000-
2G24FE SPMs.
(For details on connecting or removing a mini-GBIC transceiver and connecting and
disconnecting a Gigabit Ethernet cable, see Chapter 4,
.)
The 5000-2XGE SPM provides port Link and Activity LEDs in addition to Power and
Status LEDs.
The following table shows the transceivers that are available with the 5000-2XGE
SPM.
Note:
The 5000-2XGE SPM can only be managed by the 5000-M2 management module.
Part Number
Description
Distance
Fiber Type
NS-SYS-GBIC-MXSR Transceiver, 300m 10 G, XFP
Short Reach
Multi-Mode Fiber
NS-SYS-GBIC-MXLR Transceiver, 10km 10 G, XFP
Long Reach
Single-Mode Fiber
NS-SYS-GBIC-MXER Transceiver, 40km 10 G, XFP
Extended Reach
Single-Mode Fiber
Power LED
Status LED
Transmit/
Receive LED
Link LED
Two 10-Gigabit
mini-GBIC Ports
