Chapter 2 Installing the Device
16
User’s Guide
NetScreen-5200 Mid-Mount
To mid-mount the NetScreen-5200, you need four fitted screws, a Phillips-head
screwdriver, and brackets.
To mid-mount the NetScreen-5200:
1.
Screw the left and right brackets to the middle of each side of the chassis.
2.
Screw the left and right brackets to the rack, shown below.
NetScreen-5400 Front Mount
To front mount the NetScreen-5400, you need four fitted screws, a Phillips-head
screwdriver, and brackets.
To front mount the device:
1.
Screw the front mount bracket to the front of the chassis, as shown below.
2.
Screw the left and right brackets to the rack.
