Chapter 1 Overview
4 User’s Guide
The DC Power Supply
The DC power supply weighs about three pounds. The faceplate contains a power LED, a
power switch, a cooling fan vent, and three DC power terminal blocks that connect to
power cables.
The figure below shows the NetScreen-5200 DC power supply.
The AC Power Supply
The AC power supply weighs about three pounds. The faceplate contains a power LED, a
power switch, a male power outlet, and a cooling fan vent.
The figure below shows the NetScreen-5200 AC power supply.
Thumbscrew
Power
LED
DC Power
Terminal
Blocks
Power Switch
Grounding
Screw
Fuse
Power
LED
Power Switch
Male
Power
Outlet
Thumbscrew
