Center Mount Rigging Mounting Hardware
(CTMT-F/CTMT-FJ)
(CGE) w/ Van Seats For TDX SP/SP-GT/SR
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1146629 Kit, Center Mount Rigging Mounting Hardware For
Van Seat 1 1 1 A
Tie Wrap (11-1/2" L) 1 2 2
Screw, Hex Head w/ Patch (5/16-18 x 5/8") 1 5 3
Plug Button, Black (1") 1 2 4
Locknut (#10-32) 1 1 5
Bracket, Release Handle, Black, Van Seat 1 1 6
Plug Button, Black (3/4") 1 2 7
Nut, Square (#10-32) 1 1 8
Screw, Phillips Pan Head (#10-32 x 1") 1 1 9
NLA - Washer, Plain (3/16 x 1/2 x 1/16") 1 1 10
Screw, Phillips Pan Head w/ Patch (#10-32 x 1-5/8") 1 1 11
Pin, Quick Release (5" Long) 1 1 12
Screw, Shoulder Hex Socket Head (5/16" x 1-5/8",
1/4-20) 1 1 13
Washer, Flat (5/16 x 5/8 x 1/16") 1 1 14
Locknut (1/4-20) 1 1 15
Spacer (5/16 x 7/16 x 3/8") 1 2 16
Cable/Brake Assembly 1 1 18
Screw, Phillips Pan Head (#10-32 x 11/16") 1 2 19
NLA - Washer, Lock (3/16 x 5/16 x 1/32") 1 2 20
Housing, Ratchet 1 1 21
Bearing, Glide 1 2 22
1147077 Support, Center Mount Rigging For Van Seat, Black 1 1 23
1121079 Cable/Brake Assembly w/ Ratchet Housing and
Glide Bearing 1 1 17 B
A - Includes items 2-22
B - Includes items 19-22 NOTE:
