Invacare 3G Storm Series - Manual (Page 70)

Power Center Mount Elevating Legrest - Articulating
Mounting Hardware (LNX/LNX-L)
Replacement components/Kits are for existing LNX/LNX-L Front Riggings already in the field. A customer
cannot retrofit LNX/LNX-L Front Riggings in the field. The wheelchair must be returned to Invacare
Technical Service Department for installation. Wheelchairs equipped with smart actuators cannot retrofit
to LNX/LNX-L Front Riggings at all.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1168685 Kit, LNX/LNX-L Power Center Mount Elevating
Legrest Mounting Hardware (16" - 19" D) 1 1 1 A
Bar, Extension, Power Center Mount (16 - 19" D) 1 2 2
Bracket, Rear, Power Center Mount 1 1 3
Spacer, Coved (1/4 x 11/16 x 1/2") 1 4 4
Screw, Hex Head (3/8-16 x 1-1/4") 1 2 5
Washer, Plain (1/4 x 9/16 x 1/16") 1 2 6
Locknut, Low Profile (3/8-16) 1 2 7
Screw, Hex Head w/ Patch (1/4-20 x 3/4") 1 6 8
Washer (1/4 x 1/2 x 1/16") 1 4 9
Bracket, LNX/LNX-L Mounting, Black - Right 1 1 10
Bracket, LNX/LNX-L Mounting, Black - Left 1 1 10
1168686 Kit, LNX/LNX-L Power Center Mount Elevating
Legrest Mounting Hardware (19" - 20" D) 1 1 1 A
Bar, Extension, Power Center Mount (19 - 20" D) 1 2 2
Bracket, Rear, Power Center Mount 1 1 3
Spacer, Coved (1/4 x 11/16 x 1/2") 1 4 4
Screw, Hex Head (3/8-16 x 1-1/4") 1 2 5
Washer, Plain (1/4 x 9/16 x 1/16") 1 2 6
Locknut, Low Profile (3/8-16) 1 2 7
Screw, Hex Head w/ Patch (1/4-20 x 3/4") 1 6 8
Washer (1/4 x 1/2 x 1/16") 1 4 9
Bracket, LNX/LNX-L Mounting, Black - Right 1 1 10
Bracket, LNX/LNX-L Mounting, Black - Left 1 1 10
1168687 Kit, LNX/LNX-L Power Center Mount Elevating
Legrest Mounting Hardware (21" - 22" D) 1 1 1 A
Bar, Extension, Power Center Mount (21-22" D) 1 2 2
Bracket, Rear, Power Center Mount 1 1 3
Spacer, Coved (1/4 x 11/16 x 1/2") 1 4 4
Screw, Hex Head (3/8-16 x 1-1/4") 1 2 5
Washer, Plain (1/4 x 9/16 x 1/16") 1 2 6
Locknut, Low Profile (3/8-16) 1 2 7
Screw, Hex Head w/ Patch (1/4-20 x 3/4") 1 6 8
Washer (1/4 x 1/2 x 1/16") 1 4 9
Bracket, LNX/LNX-L Mounting, Black - Right 1 1 10
Bracket, LNX/LNX-L Mounting, Black - Left 1 1 10
A - Includes items 2-10 NOTE:
