Front Riggings Reference Chart
For AT5544, 60HD, 70NHD, PW93, PHW93
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/ Slide tube attaching hardware not included.
NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
1651 = Composite footplate with 9-7/8" curved pivot/ slide tube.
AT5543 = Adjustable angle footplate with 9-7/8" straight pivot/ slide tube.
1350 = Extra large footplate with "L" style pivot/ slide tube.
Support Assemblies
Pivot/Slide tube and footplates are interchangeable with the support assemblies listed.
Rigging
Type
AT5544 60HD 70NHD PW93 PHW93
8881126089 8881070776 8881053149 8881053158 8881045291
Right
See Note(s) C See Note(s) B, A See Note(s) A, C See Note(s) B, A See Note(s) C, A See Note(s) D, A
8881126090 8881070777 8881053148 8881053157 8881045292
Left
See Note(s) A, B See Note(s) A, C See Note(s) A, B See Note(s) C, A See Note(s) A, D
A - Specify frame color when ordering, see page titled "Frame Finishes and Touch-Up Paints".
B - Offered on 3G Storm Series and TDX SP/SR models.
C - Offered on 3G Storm Series models.
D - Offered on TDX SP/SR models. NOTE:
Pivot/ Slide Tube and Footplates
Footplate
Type
AT5543
14-15" W
AT5543
16-24" W
1651
13-14" W
1651
15-16" W
1651
17-24" W
1350
17-24" W
AT5543
12-13" W
1062756 1060444 1060442 1026395 1057879 1057869 1057859 Right
1062757 1060445 1060443 1026396 1057880 1057870 1057860 Left
14
