Front Riggings Reference Chart
For P904, PAL4A, PHAL4A
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/Slide tube attaching hardware not included.
NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
1650 = Aluminum footplate with "L" style pivot/slide tube.
AT5543 = Adjustable angle footplate wtih 9-7/8" straight pivot/slide tube.
1350 = Extra large footplate with "L" style pivot/slide tube.
Support Assembly
Pivot/Slide tube and footplates are interchangeable with the support assemblies listed.
Rigging
Type
P904
8881058646
Right
See Note(s) B, A
8881058647
Left
See Note(s) B, A
A - Specify Frame Color when ordering, see page titled "Frame Color and Touch-Up Paint".
B - Offered on 3G Storm Series models only NOTE:
Pivot/Slide Tube and Footplates
Footplate
Type
1650
14-15" W
1650
16-24" W
1350
17-24" W
AT5543
14-15" W
AT5543
16-24" W
1062756 1060444 1058830 1058604 1058612 Right
1062757 1060445 1058831 1058605 1058613 Left
2" Longer Pivot/Slide Tube and Footplates
Footplate
Type
1650
14-15" W
1650
16-24" W
1350
17-24" W
AT5543
14-15" W
AT5543
16-24" W
1062760 1062758 1086541 1086529 N/A Right
1062761 1062759 1086551 1086531 N/A Left
16
