Adjustable Angle Footplate Assembly - AT5543
90°, 70°, PHW93, AT5544, PH93M2, PHAL4A Swingaway Supports
NOTE: Heel loops are not included. See footrest and legrest accessories.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart Pivot/Slide Tube w/ Footplate Assemblies 1 1 1 A
1113572 Footplate, Adjustable Angle, Medium, Black (4-1/4"
W x 8" L) 1 1 2 B,F
1113573 Footplate, Adjustable Angle, Large, Black (5-1/4" W
x 8" L) 1 1 2 C,F
1113574 Footplate, Adjustable Angle, Extra Large, Black
(6-1/4" W x 8" L) 1 1 2 D,F
1058517 Clamp, Footplate 1 1 3
1057855 Tube, Pivot and Slide, Straight, Steel, Black (9-7/8"
L) 1 1 4
1057856 Tube, Pivot/Slide, Straight, Steel, Black (11-7/8" L) 1 1 4
1121135 Tube, Pivot/Slide, Straight, Steel, Black (13-7/8" L) 1 1 4
1091745 Tube, Pivot/Slide, Straight, Steel, Chrome (13-7/8"
L) 1 1 4 E
1048816 Screw, Nylon Adjustment (1/2-13 x 7/8") 1 1 5
1052102 Hinge, Footplate - Right 1 1 6
1052103 Hinge, Footplate - Left 1 1 6
1029545 Screw, Socket Flat Head (1/4-20 x 3/4") 1 2 7
7930321 Package, Screw, Socket Button Head (1/4-20 x
1-7/8") 25 1 8
1026900 Washer (1/4 x 23/32 x 1/16") 1 1 9
7930313 Package, Washer, Nylon (5/16 x 7/8 x 1/8") 25 1 10
1036435 Washer, Nylon (1/4 x 7/8 x 1/32") 1 1 11
1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 1 12
1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 1 13
1026907 Washer (1/4 x 1/2 x 1/16") 1 1 14
7930333 Locknut (1/4-20) 25 1 15
1082686 Nut, Barrel, Hex Head (1/4-20 x 11/16") 1 2 16
A - Includes Items 2 thru 16.
B - For 12-13" wide chairs.
C - For 14-15" wide chairs.
D - For 16" and wider chairs.
E - For PAS4A and PAL4A only.
F - This footplate was revised on 9/2/2008 with rounder corners and accessory holes changed from 8 to 4. Recommended to
replace footplate in pairs to match sides.
NOTE:
#1 Pivot/Slide Tube w/ Footplate Assemblies
Rigging Type
90 and 70MFX
(9-7/8" Tube)
60, 60MFX, 70
PW93, PW93E
AT5544, P904
(9-7/8" Tube)
60, 60MFX, 70
PW93, PW93E
AT5544, P904
(11-7/8" Tube)
60, 60MFX, 70
PW93, PW93E
AT5544, P904
(13-7/8" Tube)
PAS4A and
PAL4A
(13-7/8" Tube)
N/A 1121136 N/A 1060442 1060436
12-13" W - Right
(4-1/4" Footplate)
50
