Power Elevating Legrest - Articulating
(MPCTMT/MPCTMT-L)
For TDX SP/SP-GT/SR (Before 01/01/09)
NOTE: A complete set of Power Elevating Legrest-Articulating must be ordered thru Invacare's
Equipment Configurator. Request Customer Service to review their reference document "Parts Pal" first
before ordering.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1143748 Pan, Seat, with Hook and Loop Fasteners (16 - 20"
W x 16 - 19" D) 1 1 1 A,B
1143789 Pan, Seat, with Hook and Loop Fasteners (16 - 20"
W x 19 - 22" D) 1 1 1 A,B
1143790 Pan, Seat with Hook and Loop Fasteners (20 - 24"
W x 16 - 19" D) 1 1 1 A,B
1143791 Pan, Seat, with Hook and Loop Fasteners (20 - 24"
W x 19 - 22" D) 1 1 1 A,B
1147045 Kit, Power Elevating Legrest-Articulating Mtg. Hdwr.
(MPCTMT/MPCTMT-L) 1 1 2 B
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 3
Spacer (1/4 x 3/8 x 3/16") 1 4 4
Cap, End, Side Rail, Black 1 2 5
Block, Threaded 1 2 6
1148708 Harness, Power Elevating Legrest-Articulating
(MPCTMT/MPCTMT-L) 1 1 7 E
1101401 Harness, ELRPW Power Legrest - Left 1 1 8 E
1142235 Motor, MPCTMT Smart Actuator 1 1 9 G
1153719 Kit, MPCTMT Actuator Motor Mounting Hardware 1 1 10 C
Screw, Socket Head (3/8-16 x 2-1/2") 1 1 11
Spacer (3/8 x 1 x 1/2") 1 3 12
Locknut (3/8-16) 1 1 13
Screw, Socket Head w/ Patch (3/8-16 x 2") 1 1 14
1021742 Screw, Phillips Pan Head (#4-40 x 1/2") 1 4 15
1151959 Center Mount Leg Integrated Actuator Module
(CMLIAM) for MPCTMT Legrest w/ Smart Actuator
(54" L) 1 1 16 F
1142951 Rail, Seat Frame (For 12 - 19" D Conventional) 1 1 D,D1
1142952 Rail, Seat Frame (For 19 - 22" D Conventional) 1 1 D,D1
A - When ordering a complete set of Power Elevating Legrest-Articulating for the first time for chairs manufactured before
3/5/07, a frontal notched out Seat Pan must be ordered separately.
B - Includes items 3-6
C - Includes items 11-14. Part # 1153719 Mounting Hardware can be used for both MPCTMT Conventional and Smart
Actuator Motors
D - Not Shown. When a customer is ordering Power Elevating Legrest for the first time and a Contoura Seating System is
used, the shorter seat rails used for Conventional Backs must be ordered also.
D1 - This will prevent the legrest from being positioned to far forward
E - Items 7 and 8 are used for a MPCTMT Conventional Actuator Motor only. Item #8 is used for both ELRPW and MPCTMT
Power Legrest applications.
F - Item 16 is not used when MPCTMT Legrest are ordered with a MPCTMT Conventional Actuator Motor
G - Refer to Motion Concepts at 1-888-433-6818 when replacing the MPCTMT Conventional Actuator Motor
NOTE:
