Front Riggings Reference Chart
For P904, PAL4A, PHAL4A
4" Longer Pivot/Slide Tube and Footplates
Footplate
Type
1650
14-15" W
1650
16-24" W
1350
17-24" W
AT5543
14-15" W
AT5543
16-24" W
N/A N/A 1086542 1086530 N/A Right
N/A N/A 1086552 1086532 N/A Left
Support Assembly
Pivot/Slide tube and footplates are interchangeable with the support assemblies listed.
Rigging
Type
PAL4A/PHAL4A (Chrome Only)
1058482
PAL4A - Right
See Note(s) A
1058483
PAL4A - Left
See Note(s) A
1031437
PHAL4A - Right
See Note(s) B
1031438
PHAL4A - Left
See Note(s) B
A - Offered on 3G Storm Series models only
B - Offered on TDX SP models only NOTE:
Pivot/Slide Tube and Footplates
Footplate
Type
1650
14-15" W
1650
16-24" W
1350
17-24" W
AT5543
14-15" W
AT5543
16-24" W
1091777 1091775 1035456 1023907 1023905 Right
1091778 1091776 1035457 1023908 1023906 Left
17
