Front Rigging Hangers and Hardware
Pin, Sector and Hemi Style (16"-24" Wide) (CGR, CGTR, CGTRE)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1172005 Kit, Front Center Seat Frame Crossmember w/
Hardware 1 1 1 A
Spacer (1/4 x 3/8 x 3/16") 1 4 2
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 3
Locknut (1/4-20) 1 2 4
Screw, Socket Head (1/4-20 x 1-1/4") 1 2 5
Cap, End, Side Rail, Black 1 2 6
Support, Seat Pan (16-24" Wide) 1 2 7
Crossmember, Front Center Seat Frame, Black 1 1 8
1047449 Spacer (1/4 x 3/8 x 3/16") 1 4 2
1038379 Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 3
1025195 Locknut (1/4-20) 1 2 4
1003545 Screw, Socket Head (1/4-20 x 1-1/4") 1 2 5
1120286 Cap, End, Side Rail, Black 1 2 6
1121728 Support, Seat Pan (16-24" Wide) 1 2 7
1121714 Crossmember, Front Center Seat Frame, Black 1 1 8
1143781 Front Rigging Hanger Assembly w/ Plug Button, Pin
Style, Adult, Black - Right 1 1 9
1143782 Front Rigging Hanger Assembly w/ Plug Button, Pin
Style, Adult, Black - Left 1 1 9
1134426 Package, Plug Button, Black (3/4") 10 1 10
1143416 Front Rigging Hanger Assembly w/ Sector Block,
Black - Right 1 1 11 B
1143417 Front Rigging Hanger Assembly w/ Sector Block,
Black - Left 1 1 11 B
1054571 Kit, Sector Block - Right 1 1 12 C
1054572 Kit, Sector Block - Left 1 1 12 C
1143783 Front Rigging Hanger Assembly w/ Plug Button,
Hemi, Black - Right 1 1 13 D
1143784 Front Rigging Hanger Assembly w/ Plug Button,
Hemi, Black - Left 1 1 13 D
A - Includes items 2-8
B - Includes Front Rigging Hanger and item 12
C - Includes the Sector Block, Screw and Washer
D - Used for TDX SP/SR models only NOTE:
24
