Center Mount Rigging Mounting Hardware
(16"-24" Wide) (CGT,CGTE, CGR, CGTR, CGTRE) For TDX SP/SP-GT/SR
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1147095 Kit, CTMT-F Center Mount Riggings Mounting
Hardware (16" - 19" D) 1 1 1 A
Screw, Socket Button Head (1/4-20 x 1-1/2") 1 1 2
Tie Wrap (11-1/2" L) 1 2 3
Spacer (1/4 x 3/8 x 3/16") 1 4 4
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 5
T-Nut (5/16-18) 1 1 6
Screw, Socket Head (#10-32 x 1/2") 1 1 7
Bracket, Release Handle Mounting, Black 1 1 8
Screw, Hex Head w/ Patch (5/16-18 x 1/2") 1 1 9
Nut, Square (#10-32) 1 1 10
Plug, Support 1 2 11
Support, Footrest, Center Mount Rigging, Black
(16"-19" D) 1 1 12
Screw, Socket Head (1/4-20 x 1-1/4") 1 2 13
Locknut (1/4-20) 1 3 14
Support, Seat Pan (16-24" Wide) 1 2 15
Cap, End, Side Rail, Black 1 2 16
Locknut (1/4-20) 1 1 17
Housing, Ratchet 1 1 18
Bearing, Glide 1 2 19
Pin, Quick Release (5" Long) 1 1 20
Cable/Brake Assembly 1 1 21
NLA - Washer, Lock (3/16 x 5/16 x 1/32") 1 2 22
Screw, Phillips Pan Head (#10-32 x 11/16") 1 2 23
Screw, Shoulder Hex Socket Head (5/16" x 1-5/8",
1/4-20) 1 1 24
1146336 Support, Footrest, Center Mount Rigging, Black
(16"-19" D) 1 1 12
1113389 Housing, Ratchet 1 1 18
1113383 Bearing, Glide 1 2 19
1113622 Cable/Brake Assembly 1 1 21
1028527-NLA NLA - Washer, Lock (3/16 x 5/16 x 1/32") 1 2 22
40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 2 23
1121079 Cable/Brake Assembly w/ Ratchet Housing and
Glide Bearing 1 2 25 B
1147096 Kit, CTMT-F Center Mount Riggings Mounting
Hardware (19"-22" Deep) 1 1 1 A
Screw, Socket Button Head (1/4-20 x 1-1/2") 1 1 2
Tie Wrap (11-1/2" L) 1 2 3
Spacer (1/4 x 3/8 x 3/16") 1 4 4
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 5
T-Nut (5/16-18) 1 1 6
Screw, Socket Head (#10-32 x 1/2") 1 1 7
92
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 07_077
