Adductor Mounting Hardware, Tilt/Recline, Sector Style
For replacement Adductors, see section titled, "Accessories-Adductors" within the Formula™CG
Powered Seating Elevate CGE Tilt CGT/CGTE Recline CGR Tilt/Recline CGTR/CGTRE parts book.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1162437 Kit, Adductor Mounting Hardware, Tilt/Recline w/
Sector Front Riggings 1 1 1 A
Screw, Socket Head (1/4-20 x 1-1/4") 1 2 2
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 3
Locknut (1/4-20) 1 2 4
Crossmember, Front Center Seat Frame, Black 1 1 5
Support, Seat Pan (16-24" Wide) 1 2 6
Front Rigging Hanger Assembly w/ Sector Block,
Black - Right 1 1 7
Front Rigging Hanger Assembly w/ Sector Block,
Black - Left 1 1 7
A - Includes items 2-7. NOTE:
