Invacare 3G Storm Series - Manual (Page 65)

Power Elevating Legrest - Articulating
(MPCTMT/MPCTMT-L)
For TDX SP/SP-GT/SR (After 12/31/08)
Replacement parts for chairs with MPCTMT built after 12/31/08.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
Spacer, Coved (1/4 x 11/16 x 1/2") 1 4 4
Screw, Hex Head (3/8-16 x 1-1/4") 1 2 5
Washer, Plain (1/4 x 9/16 x 1/16") 1 2 6
Locknut, Low Profile (3/8-16) 1 2 7
Screw, Hex Head w/ Patch (1/4-20 x 3/4") 1 6 8
Washer (1/4 x 1/2 x 1/16") 1 4 9
1163373 Kit, Calf Pad (Pair) 1 1 12 G
Pad, Calf (4-1/2" W x 7-1/4" L) 1 2
Screw, Socket Button Head w/ Patch (1/4-20 x 3/4") 1 4
1162452 Motor, MPCTMT Smart Actuator 1 1 13 K
1168449 Kit, MPCTMT Conventional Actuator Motor and
Mounting Hardware 1 1 13 L
1168410 Kit, MPCTMT Actuator Motor Mounting Hardware 1 1 M
1164849 Footboard w/ Hardware Assembly,
MPCTMT/MPCTMT-L 1 1 14 D
1164309 Footplate w/ Hardware Assembly,
MPCTMT/MPCTMT-L 1 1 15 E
1148708 Harness, Power Elevating Legrest-Articulating
(MPCTMT/MPCTMT-L) 1 1 16 H
1101401 Harness, ELRPW Power Legrest - Left 1 1 17 H
1021742 Screw, Phillips Pan Head (#4-40 x 1/2") 1 4 18
1151959 Center Mount Leg Integrated Actuator Module
(CMLIAM) for MPCTMT Legrest w/ Smart Actuator
(54" L) 1 1 19 I
1147045 Kit, Power Elevating Legrest-Articulating Mtg. Hdwr.
(MPCTMT/MPCTMT-L) 1 1 20
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 21
Spacer (1/4 x 3/8 x 3/16") 1 4 22
Cap, End, Side Rail, Black 1 2 23
Block, Threaded 1 2 24
A - Includes items 2-9.
B - For use with MPCTMT Conventional Actuator Motor.
C - For use with MPCTMT Smart Actuator Motor.
D - Includes Footboard and attaching hardware.
E - Includes Footplates and attaching hardware.
F - Not shown. Includes items 4-9.
G - Includes Calf Pads and hardware.
H - Items 16 and 17 are used for a MPCTMT Conventional Actuator Motor only. Item #17 is used for both ELRPW and
MPCTMT Power Legrest applications.
I - Item 18 is not used when MPCTMT Power Elevating-Articulating Legrest are ordered with a MPCTMT Conventional
Actuator Motor
J - Use existing mounting hardware to attach the mounting bracket.
K - The MPCTMT Smart Actuator Motor does not include the MPCTMT Actuator Motor Mounting Hardware part #1168410.
L - The MPCTMT Conventional Actuator Motor includes the MPCTMT Actuator Motor Mounting Hardware part #1168410.
M - Not Shown. MPCTMT Actuator Motor Mounting Hardware can be used for Conventional and Smart MPCTMT Actuator
Motors. Individual components are non-saleable.
NOTE:
64
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 07_077
