Adductor Mounting Hardware - Jr. Center Mount Front
Riggings - Tilt
For replacement Adductors, see section titled, "Accessories-Adductors" within the Formula™CG
Powered Seating Elevate CGE Tilt CGT/CGTE Recline CGR Tilt/Recline CGTR/CGTRE parts book.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1162444 Kit, Adductor Mounting Hardware, Jr. Center Mount,
Tilt 1 1 1 A
Screw, Hex Head w/ Patch (5/16-18 x 5/8") 1 4 2
Spacer (5/16 x 7/16 x 3/8") 1 2 3
Block, Threaded 1 2 4
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 4 5
Screw, Socket Button Head (1/4-20 x 1-1/2") 1 1 6
Locknut (1/4-20) 1 1 7
Housing, Ratchet 1 1 8
Screw, Shoulder Hex Socket Head (5/16" x 1-5/8",
1/4-20) 1 1 9
Locknut (1/4-20) 1 1 10
Bearing, Glide 1 2 11
Pin, Quick Release (5" Long) 1 1 12
Tie Wrap (11-1/2" L) 1 2 13
T-Nut (5/16-18) 1 1 14
Bracket, Release Handle Mounting, Black 1 1 15
Screw, Hex Head w/ Patch (5/16-18 x 1/2") 1 1 16
Screw, Socket Head (#10-32 x 1/2") 1 1 17
NLA - Washer, Lock (3/16 x 5/16 x 1/32") 1 2 18
Screw, Phillips Pan Head (#10-32 x 11/16") 1 2 19
Nut, Square (#10-32) 1 1 20
Cable/Brake Assembly 1 2 21
Support, Footrest, Center Mount Rigging, Black 1 1 22
Plug, Support 1 2 23
1121079 Cable/Brake Assembly w/ Ratchet Housing and
Glide Bearing 1 1 21
A - Includes items 2-23. NOTE:
123
