IBM ADSL Bridge/ Router Heritage User Manual

Page 50

Heritage Series ADSL Bridge/ Router

4-5

Advanced Configurations

• Add NAT to RFC 1483 to above RFC 1483 Routing Mode example

> ip nat add mpoa

↵

(ipoa is the device name same as you configure in RFC 1483 example)

• Remove NAT to RFC 1483 to above RFC 1483 Routing Mode example

> ip nat delete mpoa

↵

• Add NAT to RFC 1577 to above RFC 1577 Routing Mode example

> ip nat add ipoa

↵

(ipoa is the device name same as you configure in RFC 1577 example)

• Remove NAT to RFC 1577 to above RFC 1577 Routing Mode example

> ip nat delete ipoa

↵

• Add NAT to RFC 2364/RFC2516 to above RFC 2364/RFC2516 Routing

Mode example

> ip nat add ppp_device

↵

(ppp_device is the device name same as you configure in RFC 2364/RFC2516

example)

• Remove NAT to RFC 2364/RFC2516 to above RFC 2364/RFC2516

Routing Mode example

> ip nat delete ppp_device

↵
