Heritage Series ADSL Bridge/ Router
1-9 Introduction
1.6 Rear Panel
The rear panel of the xDSL Router consist of power jack, Console Port
connector, Ethernet connect and xDSL link jack which they means as
below:
Function Definition
xDSL
xDSL jack connect to DSL line from TelCo.
10Base-T or
10/100Base-T Ethernet interface connect to PC or HUB for
LAN.
Console This is RS232C interface and use to
management xDSL Router.
DC 9V or
DC12V The power jack connects to Adaptor from wall
outlet.
The rear panel of the xDSL Router which including 4-port stackable switch
hub consist of power jack, Console Port connector, Ethernet connects and
xDSL link jack which they means as below:
Function Definition
xDSL
xDSL jack connect to xDSL line from TelCo.
Up-Link This is HUB feature cascade to another HUB for
expand LAN.
L1 ~ L4 Ethernet Ports: Port1 to Port4
Console This is RS232C interface and use to
management xDSL Router.
DC 9V The power jack connects to Adaptor from wall
outlet.
