3-6 Basic Configurations
> ip device add mpoa ptp //bun/port=r1483/rfc1483=true/mode=/
txvpi=/txvci=/rxvpi=/rxvci= 10.99.48.50
↵
(assume 10.99.48.50 is the static IP address assigned by your service provider for
the PC); ( is the encapsulation mode of RFC1483, it can be one of LlcRouted
and VcMuxRouted, and the setting of encapsulation mode is case sensitivity.
is the VPI value, and is the VCI value)
> ip route add default 0.0.0.0 10.99.48.1 0:0:0:0
↵
(10.99.48.1 is the IP address of your service provider)
> ip relay all
↵
(enable routing between rfc1483 and ethernet ports)
config save
↵
restart
↵
You can use following procedure to remove existing RFC 1483 setting.
> isfs rm resolve
↵
> isfs rm initbridge
↵
> isfs rm initppp
↵
> restart
↵
