IBM ADSL Bridge/ Router Heritage - Manual (Page 118)

Heritage Series ADSL Bridge/ Router
7-53 Command Sets for Command Line Interface
2. config
Syntax:
config [save]
Description:
Displays the configuration (as from “access list” and “trap
list
” together), or saves it to flash memory.
Example:
DSL> snmp config
access read public
access write xyzzy 192.168.4.73
trap add public 192.168.4.73 162
3. trap
Syntax:
trap add []
trap delete []
trap flush
trap list
Description:
Manipulates the list of destinations to which SNMP traps will be sent.
The default UDP port to send traps to is 162, but it may be overridden
by specifying .
Configuration saving saves the list of trap destinations.
Example:
DSL> snmp trap flush
DSL> snmp trap add public 192.168.4.73
DSL> snmp trap add public 192.168.4.74 999
DSL> snmp trap list
trap add public 192.168.4.73 162
trap add public 192.168.4.74 999
