Heritage Series ADSL Bridge/ Router
Table of Contents
Chapter 1 Introduction
1-1
1.1 Overview 1-1
1.2 Features and Compatibility 1-2
1.3 What’s in the package? 1-4
1.4 Important Rules for Safe Operation 1-5
1.5 Front Panel 1-8
1.6 Real Panel 1-9
Chapter 2 Installing and Configuring your xDSL
Router 2-1
2.1 Preparation for Hardware and Software Installation 2-2
2.2 Hardware Installation 2-4
2.3 Windows 95/98 setting for Ethernet LAN connection 2-5
2.3.1 Check TCP/IP protocol 2-5
2.3.2 TCP/IP installation 2-7
2.3.3 TCP/IP setting 2-9
2.4 Configuring the Router 2-12
2.4.1 Using TELNET via Ethernet interface 2-12
2.4.2 Using terminal program via serial console port 2-13
Chapter 3 Basic Configurations 3-1
3.1 Factory default configuration 3-2
3.2 Bridged RFC1483 3-3
3.3 Routed RFC1483 3-5
3.4 Classical IP (RFC1577) 3-7
3.5 PPP Over ATM (RFC2364) 3-9
3.6 PPP Over Ethernet (RFC2516) 3-13
Chapter 4 Advanced Configurations 4-1
4.1 Add NAT to Classic IP, PPP over ATM and PPP over
Ethernet 4-2
