9
1 Description
Server Board Features
Table 1. Server Board Features
Feature Description
Processor Up to two 1.8 GHz to 2.4 GHz Intel ® Xeon ™ processors with 512K cache
support packaged in a 603-pin micro Pin-Grid Array (PGA)
System Bus Frequency 400 MHz Front Side Bus
Memory (DRAM) Six 72-bit sockets for 184-pin, 200 MHz, 2.5 V, DDR200 or DDR266 compliant,
registered, ECC, SDRAM single-sided or double-sided memory
modules (DIMM)
Video Memory 8 MB SDRAM of video memory
PCI bus • One PCI-X 133 MHz/64-bit 3.3 V full-length expansion slot for an add-in
board (see “Enabling PCI-X on Slot 6 and Disabling On-board SCSI” on
page 90)
• Two PCI-X 100 MHz/64-bit full-length expansion slots
• Three standard PCI 33 MHz/32-bit full-length expansion slots for add-in
boards
Graphics Integrated onboard ATI Rage † XL 32-bit SVGA controller
SCSI Adaptec † AIC-7899W dual channel Ultra160 SCSI, supporting onboard Ultra 2
(LVD) wide, Ultra-wide, and Ultra160 SCSI interfaces
Network Two integrated onboard Network Interface Controllers (NICs):
• An Intel ® 82550PM single-chip PCI LAN controller for 10Base-T/100BaseTX
Fast Ethernet networks
• An Intel ® 82544GC single-chip Gigabit Ethernet Controller capable of
providing 10/100/1000 Mbps data rates
Two RJ-45 Ethernet connectors at the I/O back panel
System I/O
• PS/2 † -compatible keyboard and mouse ports, 6 pin DIN
• IEEE 1284-compliant, 25-pin, bi-directional parallel port
• VGA video port, 15-pin
• Two serial ports, one 9-pin on the rear I/O and one through a 10-pin header
on the baseboard
• Two RJ-45 Ethernet ports
• Four USB ports, three on the rear I/O and one through a 10-pin header on
the baseboard
Form Factor Server ATX form factor, ATX 2.03 compliant I/O SSI Entry E-Bay 3.0
