Appendix G: Quick Reference of Common Tasks

iSPAN PRI PCI ISDN Users Guide

123

Supply an IP
address from a
static address pool
to a remote user

1. From the Start menu, select Settings, and then

Control Panel.

2. Double-click the Network icon, and select the

Services tab.

3. From the services list, select Remote Access

Service, and then click Properties.

4. In the Remote Access Setup dialog, click

Network.

5. In the Network dialog, click the TCP/IP

Configure button.

6. In the RAS server TCP/IP Configuration dialog,

select the Use static address pool option.

7. Enter an IP pool address.
Using this method, the first IP address of the pool is
assigned to the server. For example, the following
figure shows IP addressing with address pool
192.1.1.1 to 192.1.1.30:

Figure G-2. IP addressing

If you want to...

Do this...

Remote Client 2

192.1.1.3

Remote Access Server

(Windows NT Server)

Remote Client 1

192.1.1.2

ISDN

192.1.1.1
