Interpreting LineStatus Indicators
110
Interphase Corporation
Interpreting LineStatus Indicators
N
OTE
The
iSPAN
-PRI is listed as the 5535 in the LineStatus
dialog.
The LineStatus dialog displays LEDs and statistics about each
adapter port. It notifies you of alarms, errors, loopback mode,
and statistics related to the port. When a port is operating under
normal conditions, all LEDs are grey.
To view LineStatus information:
1. From the Start menu, select Programs, next
INTERPHASE WAN Adapters, and then LineTest.
The main LineTest dialog appears.
Figure F-1. Main LineStatus dialog
The following sections provide detailed information about
LineStatus LEDs and statistics.
