Appendix B: Using the SynWatch Utility
iSPAN PRI PCI ISDN Users Guide
85
2. To activate frame logging for the selected channel or
port, select one of the watch modes (RAS uses the PPP
Protocol):
– X25
– PPP
– Frame Relay
– SDLC
– QLLC
– Hexadecimal Dump
For detailed information about each watch mode, see
SynWatch online help.
Watching ISDN Layer 1 Alarms
ISDN Layer 1 alarms are managed by the adapter, and are
activated when physical events occur.
To display these alarms using SynWatch:
1. In the Configuration panel of the SynWatch dialog,
right-click the PRI port for which to display alarms.
2. Select to enable Layer 1 alarms.
