Intel Express 5800/120Ld User Manual
Page 143
Problem Solving 5-21
Table 5-4. Sensor Type Codes
Sensor Number
Sensor Type
01h
Ambient Temp (MB)
02h
CPU#1 Temp
03h
CPU#2 Temp
20h
+3.3V
21h
+5V
22h
+12V
23h
+3.3Vs
24h
VCCP0 (CPU#1 VRM)
25h
VCCP1 (CPU#2 VRM)
29h
+1.5V
2Ah
+2.5V
2Ch
SCSI A +2.85V
2Dh
SCSI B +2.85V
2Eh
SCSI A Vref0
2Fh
SCSI A Vref1
30h
SCSI A Vref2
31h
SCSI B Vref0
32h
SCSI B Vref1
33h
SCSI B Vref2
40h
CPU Rear Fan (Fan #1)
41h
CPU Front Fan (Fan #2)
42h
Chassis (HDD) Fan (Fan #3)
