© Copyright IBM Corp. 2000
35
Installing options
This chapter provides instructions to help install options to the server. For a list of
supported options for the server, see the ServerProven™ list at
http://www.pc.ibm.com/compat
Expanded view of the xSeries 200
Note:
The illustrations in this document might differ slightly from your hardware.
The following illustration shows the major components of the server.
System and PCI extender board
The illustrations in the following sections show the components on the system and
PCI extender boards.
System and PCI extender board options
connectors
The following illustration identifies system board connectors for options that can be
installed.
Adapter retaining
bracket
Adapter support bracket
Drive cage
Microprocessor
Memory modules
Cover
Support bracket assembly
EMC shield
Filler
panel
Intrusion switch
Front door
