92

Hardware Maintenance Manual: xSeries 200

Error symptoms

301-XXX-000

(Failed Keyboard test)

1.

Keyboard

405-XXX-000

(Failed Ethernet test on
controller on the System
Board)

1.

Verify that Ethernet is not disabled in BIOS.

2.

System Board

405-XXX-00N

(Failed Ethernet test on
adapter in PCI slot N)

1.

Adapter in PCI slot N.

2.

System Board

415-XXX-000

(Failed Modem test)

1.

Cable

2.

Modem

3.

System Board

General

FRU/Action

CD is not working properly.

1.

Clean the CD.

2.

Run CD-ROM diagnostics.

3.

CD-ROM Drive

CD-ROM drive tray is not
working.

(The server must be
powered-on.)

1.

Insert the end of a paper clip into the manual tray-release opening.

2.

Run CD-ROM diagnostics.

3.

CD-ROM Drive

CD-ROM drive is not
recognized.

1.

Run Configuration/Setup, enable primary IDE channel.

2.

Check cables and jumpers.

3.

Check for correct device driver.

4.

Run CD-ROM diagnostics.

5.

CD-ROM drive

6.

System Board

Power switch does not work.

1.

Verify that switch number 5 of switch block is Off.

2.

Power Switch Assembly

3.

System Board

CD-ROM drive cable is not
plugged in.

1.

Make sure CD-ROM drive cable is plugged in.

Error Code/Symptom

FRU/Action
