PCI-6886 User’s Manual
84
Appendix C System Assignments
C.1 System I/O Ports
Table C.1: System I/O ports
Addr. range (Hex)
Device
00-0F
Master DMA controller
20-21F
Master Interrupt controller
40-5F
Timer/Counter
60-6F
Keyboard controller
(60h)
KBC Data
(61h)
Misc Funtions & Spkr Ctrl
(64h)
KBC Command/Status
70-77
RTC/COMS/NMI-Disable
78-7F
-available for system use-
80
-reserved-(debug port)
81-8F
DMA Page Registers
90-91
-available for system use-
92
System Control
93-9F
-available for system use-
A0-A1H
Slave Interrupt Controller
C0-DF
Slave DMA Controller
E0-FF
-available for system use-
100-1EF
-available for system use-
170-178
Secondary IDE Control
1F0-1F8
Primary IDE Control
200-20F
Game Port
295-296
Hardware Monitor
2E8-2EF
COM4
2F8-2FF
COM2
378-37F
Parallel Port(Standard & AFF)
3C0-3CF
EGA
3D0-3DF
VGA
3E8-3EF
COM3
3F0-3F1
Configuration Index/Data
3F0-3F7
Floppy Controller
3F8-3FF
COM1
778-77A
Parallel Port(ECP Extensions)(Port 378+400)
