9 Chapter 2 Installation
2.2 Connectors
On-board connectors link the PCI-6886 to external devices such as hard
disk drives, a keyboard, or floppy drives. The table below lists the func-
tion of each of the board’s connectors.
Table 2.2: Connectors
Label Function
CN1 Front Pannel Connector
CN2 Digital I/O Connector
CN3 Primary IDE Connector
CN4 Floppy Connector
CN5 ATX power Connector
CN6 Printer port Connector
CN7 Secondary IDE Connector
CN8 COM port 3, 4
CN9 USB port 3, 4
CN10 USB port 1, 2
CN11 D-SUB VGA Connector
CN12 LAN RJ45 Connector
CN13 COM port1
CN14 COM port 2
CN15 LVDS Connector
CN16 DVI Connector
CN17 AC'97 interface Connector
CN18 External KeyBoard Connector
CN19 MINI PS/2_KB/Mouse Connector
CN20 LCD inverter power connector
CN21 CompactFlash Socket
SA1 SATA Connector
SA2 SATA Connector
FAN1 CPU FAN Connector
