Chapter 2 installation, 1 jumpers, Chapter – Intel CELERON PCI-6886 User Manual
Page 18: 2 installation, Jumpers
PCI-6886 User’s Manual
8
Chapter 2 Installation
2.1 Jumpers
The PCI-6886 has a number of jumpers that allow you to configure your
system to suit your application. The table below lists the functions of the
various jumpers.
Table 2.1: Jumpers
Label
Function
JP1
COM2 RS232/422/485 Selection
JP2
CMOS Clear
JP3
LVDS Panel Power Selection
JP4
PCI Card Power Selection
