Intel CELERON PCI-6886 User Manual
Page 75
65
Appx. B
B
Pin Assignments
This appendix contains information of a
detailed or specialized nature. It includes:
• Floppy Drive Connector
• Primary IDE Connector
• LPT Connector
• Secondary IDE(Slave) Connector
• ATX Power Connector
• COM3/COM4 output
• USB1, 2 Connector
• USB3, 4 Connector
• D-SUB VGA Connector
• LAN, RJ45 Connector
• COM1 connector
• COM2 Connector
• HDD LED/Reset/Power Button
• LVDS Connector
• Audio I/F Connector
• DIO Connector
• MINI KB Connector
• EXT_KB Connector
• CompactFlash card Connector
• LCD INV PWR Connector
• DVI connector
• SATA connector
Appe
ndi
x
