IBM System Storage DR550
Version 3.0 ------17 March 2006
Page 25
IBM Storage Systems
Copyright © 2006 by International Business Machines Corporation
2005-B16
Firmware 4.4.0e (or later)
AIX 5.3
TL 04, with Atape driver 9.6.0.0 and Atldd 6.3.1.0
HACMP
5.3 + PTFs
System Storage Archive
Manager
5.3.2.0
System Storage Archive
Client
5.3.0.0
An integrated console is part of the DR550 offering. As an option, limited function is available via a
TTY type terminal (customer provided) such as a VT100 or an IBM 3151. If this option is used, the
TTY terminal is connected to the serial port on the front of the P5 520 server. It is recommended
that the integrated management console be used for all management activity.
DS4100 Logical Volume Configurations
On the DR550, LUNs will be configured based on the total storage capacity ordered. All disk
capacity is allocated for use by TSM. No disk capacity is set aside for other applications or servers.
Below are the approximate LUN configurations set at the factory. The LUN id column shows the
LUN id as seen from DS4000 Storage Manager. If you view the LUN id from AIX, it will be displayed
as a hexadecimal address.
For 5.6 TB System (single or dual node configurations)
LUN size
LUN ID
Hdisk on AIX
Logical Volume
File System
VG Name
2 GB
0
hdisk2
tsmappslv
/tsm
TSMApps
115 GB
1
hdisk3
tsmdblv tsmloglv
/tsmDb /tsmLog
TSMDbLogs
300 GB
2
hdisk4
tsmdbbkuplv
/tsmdbbkup
TSMDbBkup
2035 GB
3
hdisk5
tsmstglv1
2035 GB
4
hdisk6
tsmstglv2
380* GB
5
hdisk7
tsmstglv3
For 11.2 TB System (single or dual node configurations)
LUN size
LUN ID
Hdisk on AIX
Logical Volume
File System
VG Name
2 GB
0
hdisk2
tsmappslv
/tsm
TSMApps
115 GB
1
hdisk3
tsmdblv tsmloglv
/tsmDb /tsmLog
TSMDbLogs
300 GB
2
hdisk4
tsmdbbkuplv
/tsmdbbkup
TSMDbBkup
2035 GB
3
hdisk5
tsmstglv1
2035 GB
4
hdisk6
tsmstglv2
380* GB
5
hdisk7
tsmstglv3
2035 GB
6
hdisk8
tsmstglv4
2035 GB
7
hdisk9
tsmstglv5
600* GB
8
hdisk10
tsmstglv6
For 22.4 TB System (dual node configurations only)
LUN size
LUN ID
Hdisk on AIX
Logical Volume
File System
VG Name
2 GB
0
hdisk2
tsmappslv
/tsm
TSMApps
315 GB
1
hdisk3
tsmdblv tsmloglv
/tsmDb /tsmLog
TSMDbLogs
900 GB
2
hdisk4
tsmdbbkuplv
/tsmdbbkup
TSMDbBkup
2035 GB
3
hdisk5
tsmstglv1
2035 GB
4
hdisk6
tsmstglv2
380* GB
5
hdisk7
tsmstglv3
2035 GB
6
hdisk8
tsmstglv4
1900* GB
7
hdisk9
tsmstglv5
2035 GB
9
hdisk10
tsmstglv6
