IBM System Storage DR550
Version 3.0 ------17 March 2006
Page 24
IBM Storage Systems
Copyright © 2006 by International Business Machines Corporation
2210
Short Wave SFP GBIC (LC)
2
4603
SATA 400GB/7200 Disk Drive Module
14
5605
LC-LC 5M Fibre Optic Cable
2
7711
DS4100 AIX Host Kit
1
EXP100#1
1710-10U
DS4000 EXP100 Storage Expan
1
0707
Integrate with IBM System Storage DR550
1
2210
2 Gb Fibre Channel Short Wave GBIC
2
4603
SATA 400 GB/7200 Drive Module
14
5601
1M 50u Fiber Optic Cable (LC-LC)
2
9001
Attach to DS4100
1
Switch#1
2005-B16
IBM TotalStorage SAN Switch – 16 Port
1
0707
DR550 Integration
1
2414
4 Gb SW SFP Transceiver - 4 Pack
2
5605
Fibre Cable LC/LC 5m multimode
3
Switch#2
2005-B16
IBM TotalStorage SAN Switch – 16 Port
1
0707
DR550 Integration
1
2414
4 Gb SW SFP Transceiver - 4 Pack
2
5605
Fibre Cable LC/LC 5m multimode
3
Rack
7014-T00
7014-T00 IBM RS/6000 Rack Model T00
1
0233
Rack Content Specify: 7316-TF3 - 1 EIA
1
0234
Rack Content Specify: 1710/10U - 3 EIA
1
0247
Rack Content Specify: 7310/CR2 - 1 EIA
1
0248
Rack Content Specify: 1 EIA
2
0254
Rack Content Specify: 1724/100 - 3 EIA
1
0257
Rack Content Specify: 9131-52A - 4 EIA
2
0707
DR550 Integration (dual node)
1
6068
Front Door for 1.8 Meter Rack (Flat Black)
1
6098
Side Panel for 1.8 or 2.0 Meter Rack (Black)
2
6580
Optional Rack Security Kit
1
7188
Power Dist Unit-Side Mount, Universal UTG0247 Connector
1
9188
Power Dist Unit Specify - Base/Side Mount, Universal UTG0247 Connector 1
9300
US English Nomenclature
1
9800
United States/Canada Power Cord
1
Other configurations are available, using different amounts of DS4000 EXP100 and DS4100.
The following table highlights the versions used in DR550.
Components
Software or Firmware Levels
DS4100
NVSRAM: N1724F100R912V05
Appware: 06.12.16.00
Bootware: 06.12.16.00
DS4000 EXP100
ESM Firmware 9563
DS4000 Storage Manager
Version 9.12.6500.00
Note: (this is a special version only available with DR550. It
is not specifically ordered, but included with the hardware)
