IBM System Storage DR550 Version 3.0 ------17 March 2006 Page 18
IBM Storage Systems Copyright © 2006 by International Business Machines Corporation
DR550 Offerings
DR550 is available in both single and dual node offerings. Each offering can also be customized to
include support for tape, and the appropriate Ethernet connections.
DR550 Single Node Components
The single node DR550 offerings are built with the following components:
Quantity Key Hardware Components Description
1 7014 Model T00 RS/6000 System Rack
1 9131 Model 52A P5 520
1 1724-100 DS4100 Storage Server (includes 5.6 TB of disk capacity)
0-1 1710-10U DS4000 EXP100 Storage Expansion Unit (only installed in
11.2 TB configuration)
1 2005-B16 TotalStorage SAN Switch - with 8 shortwave transceivers
(there are 12 transceivers when enhanced RVM is included
in the order)
1 7310-CR3 eServer Hardware Management Console
1 7316-TF3 Flat Panel Monitor, Keyboard, and Mouse
The following list is a list of the actual features that are ordered for DR550 (11.2 TB). This list
should not be modified in any way as part of the initial order. IBM’s eConfig tool should be used to
review any changes in the official configurations. Other configurations are also available.
Product Description Qty
Management Console
7310-CR3
7310-CR3 Rack-mounted Hardware Management Console 1
0706 Integrate with IBM TotalStorage Storage DR550 1
0961 Hardware Management Console for POWER5 Licensed Machine Code 1
4651 Rack Indicator, Rack #1 1
6458 Power Cord (4M – 14Ft) 400V/14A, IEC320/C13, IEC320/C14 1
7801 Ethernet Cable, 6M, Hardware Management Console to System Unit 1
9300 Language Group, US English 1
7316-TF3
IBM 7316-TF3 Rack-Mounted Flat Panel Console Kit 1
0706 Integrate with IBM System Storage DR550 1
4202 Keyboard/Video/Mouse (LCM) Displays 1
4242 6 Foot Extender Cable for Displays 1
4269 USB Conversion Option 1
6350 Travel Keyboard, US English 1
9300 Language Group Specify – US English 1
9911 Power Cord (4M) All (Standard Cord) 1
5771-RS1
Initial Software Support 1 Year 1
0612 Per Processor Software Support 1 Year 1
7000 Agreement for MCRSA 1
DR550 Engine #1
9131-52A
9131 Model 52A
0706 Integrate with DR500 -- IBM TotalStorage 1
Retention Solution single node
1930 1024 MB (2X512MB) DIMMS, 276-PIN, 533 MHZ, 1
DDR-2 SDRAM
