DR550 Dual Node Components
The dual node DR550 offerings are built with the following components:
Quantity Key Hardware Components
Description
1 or 2 7014 Model T00
RS/6000 System Rack (2
nd
rack only included in 89.6 TB
configuration
2
9131 Model 52A
P5 520
1 or 2 1724-100
DS4100 Storage Server (2
nd
DS4100 included in 89.6 TB
configuration)
0-14
1710-10U
DS4000 EXP100 Storage Expansion Unit (1 included for
11.2 TB, 3 included for 14 TB, 7 included for 44.8 TB and
14 included for 89.6 TB configuration)
2
2005-B16
TotalStorage SAN Switch - with 8 shortwave transceivers
(there are 12 transceivers when configured for remote
mirroring)
1
7310-CR3
eServer Hardware Management Console
1
7316-TF3
Monitor, Keyboard, and Mouse
The following list is a list of the actual features that are ordered for DR550 (11.2 TB). This list
should not be modified in any way as part of the initial order. IBM’s eConfig tool should be used to
review the official configurations and any changes that have been implemented.
Product
Description
Qty
Management Console
7310-CR3
7310-CR3 Rack-mounted Hardware Management Console
1
0707
Integrate with IBM TotalStorage Storage DR550
1
0961
Hardware Management Console for POWER5 Licensed Machine Code
1
4651
Rack Indicator, Rack #1
1
6458
Power Cord (4M – 14Ft) 400V/14A, IEC320/C13, IEC320/C14
1
7801
Ethernet Cable, 6M, Hardware Management Console to System Unit
1
9300
Language Group, US English
1
7316-TF3
IBM 7316-TF3 Rack-Mounted Flat Panel Console Kit
1
0707
Integrate with IBM System Storage DR550
1
4202
Keyboard/Video/Mouse (LCM) Displays
1
4242
6 Foot Extender Cable for Displays
1
4269
USB Conversion Option
1
6350
Travel Keyboard, US English
1
9300
Language Group Specify – US English
1
9911
Power Cord (4M) All (Standard Cord)
1
5771-RS1
Initial Software Support 1 Year
1
0612
Per Processor Software Support 1 Year
1
7000
Agreement for MCRSA
1
DR550 Engine #1
9131-52A
9131 Model 52A
0706
Integrate with DR500 -- IBM TotalStorage
1
Retention Solution single node
1930
1024 MB (2X512MB) DIMMS, 276-PIN, 533 MHZ,
1
DDR-2 SDRAM
1968
73.4 GB 10,000 RPM Ultra320 SCSI Disk Drive
2
