Connectors

Intel® Server Board Set SE8500HW4

Revision

1.0

Intel order number D22893-001

50

7.4 USB

The Intel

®

Server Board Set SE8500HW4 has one internal USB 2.0 header.

Table 20. 4-pin Internal USB Header

Pin

Signal

1

Fused Voltage Controlled Current (VCC) (+5 V with over-current
monitoring)

2

USBP2N (differential data line)

3

USBP2P (differential data line)

4 GND

(ground)

7.5 SATA

The Intel

®

Server Board Set SE8500HW4 has one Serial ATA (SATA) header.

Table 21. SATA Connector Pinout

Pin

Signal

1 Ground

2 A+

3 A-

4 Ground

5 B-

6 B+

7 Ground
