BIOS User Interface Intel® Server Board Set SE8500HW4
Revision 1.0
Intel order number D22893-001
100
Table 68. View Memory Configure Details Menu
Setup Item Option Default Help Text Comment
Help Text for Max
Performance
This 4-way interleave
configuration provides
the maximum
performance. To get
maximum performance f
boards of same size
should be installed.
(A:B:C:D)
Help Text for Max
Compatibility
This compatibility
configuration is 1-way
interleave. It allows the
use of any number of
Memory Boards. Each
may be of different
sizes. (A),(B),(C),(D)
Help Text for Mirror
Boards (A)(B) and
(C)(D) are mirrored.
Help Text for RAID
Configuration
Performance/
Max
Compatibility/
Mirror/RAID>
RAID configuration
requires four boards of
same size to be
installed. Data is stored
on three boards while
the fourth board
contains redundancy
information.
Info Only. Configuration selected
on previous page>
Max Effective
Size size of memory
in MB> Maximum effective
memory size results
when no spares are
configured. The actual
effective size will be
calculated on the next
boot.
Info Only
Min Effective
Size size of memory
in MB> Minimum effective
memory size results
when the largest DIMMs
are used as spare (Auto
spare configuration).
The actual effective size
will be calculated on the
next boot.
Info Only
Configuration
Capabilities Characteristics of the
selected configuration.
Title only
Configuration
Possible Indicates whether the
configuration selected is Info Only
