Intel® Server Board Set SE8500HW4
Error Handling
Revision 1.0
Intel order number D22893-001
113
Code
Description
0xE2
Initial memory found, configured, and installed correctly
0xE,
0xE3
Reserved for initialization module use (PEIM)
DXE Core:
0xE4
Entered EFI driver execution phase (DXE)
0xE5
Started dispatching drivers
0xE6
Started connecting drivers
DXE Drivers:
0xE7
Waiting for user input
0xE8 Checking
password
0xE9
Entering the BIOS setup
0xEA Flash
update
0xEE
Calling Int 19. One beep unless silent boot is enabled.
0xEF Unrecoverable
Boot
failure/S3 resume failure
Runtime Phase/EFI OS Boot:
0xF4
Entering Sleep state
0xF5
Exiting Sleep state
0xF8
OS has requested EFI to close boot services
0xF9
OS has switched to virtual address mode
0xFA
OS has requested the system to reset
PEIM/Recovery:
0x30
Crisis recovery has been initiated because of a user request
0x31
Crisis recovery has been initiated by software (corrupt flash)
0x34
Loading crisis recovery capsule
0x35
Handing off control to the crisis recovery capsule
0x3F
Unable to complete crisis recovery.
12.1.2
CPU Diagnostic LEDs
The BMC provides one amber LED per processor. The LEDs are turned on when a CPU has an
error.
Table 90. Processor Diagnostic LED Locations
LED Reference Designator
Processor
DS5C1 1
DS5C2 2
DS5C3 3
DS5C4 4
