8.6 System Setting Procedure
The following is an explanation of the System Settings performed at Setting Tool.
Step1: G-50A connection set-up
Step2: Group configuration set-up
Step3: BACnet communication set-up
Step4: Notification set-up (COV, Event)
Setup for BACnet
Setup for G-50A
Step5: Expended function set-up
System setup
8.7 Setup for G-50A
Set the information of the air-conditioning system.
8.7.1 Register the G-50A
Select the [G-50] Tab. G-50A registered is displayed on a screen.
G-50A, which can be registered, is to ten sets.
(1) Add G-50A
Click the [Add] button. The [G-50] window will open →Refer to 8.7.2 and 8.7.3
(2) Modify G-50A setting
Select the [No.] of G-50A . And click the [Modify] button.
The [G-50] window will open.
→ Refer to 8.7.2 and 8.7.3
(3) Delete G-50A
Select the [No.] of G-50A . And click the [Delete] button.
The confirmation screen will open.
(4) Reset data
Click the [Reset] button. The confirmation screen will open.
