Appendices
ATV0
ATV1
X0
X1
X2
X3
X4
0
OK
3 3 3 3 3
1
CONNECT
3 3 3 3 3
2
RING
3 3 3 3 3
3
NO CARRIER
3 3 3 3 3
4
ERROR
3 3 3 3 3
5
CONNECT 1200
@
@
@
@
6
NO DIAL TONE
3
3
3
7
BUSY
3
3 3
8
NO ANSWER
3 3 3 3 3
10
CONNECT 2400
@
@
@
@
11
CONNECT 4800
@
@
@
@
12
CONNECT 9600
@
@
@
@
13
CONNECT 14400
@
@
@
@
14
CONNECT 19200
@
@
@
@
15
CONNECT 16800
@
@
@
@
18
CONNECT 57600
%
%
%
%
24
CONNECT 7200
@
@
@
@
25
CONNECT 12000
@
@
@
@
26
CONNECT 1200/75
#
#
#
#
27
CONNECT 75/1200
#
#
#
#
28
CONNECT 38400
%
%
%
%
29
CONNECT 21600
@
@
@
@
30
CONNECT 24000
@
@
@
@
31
CONNECT 26400
@
@
@
@
32
CONNECT 28800
@
@
@
@
33
CONNECT 152000
%
%
%
%
Extended Result Codes
ATW1: report DCE & DTE speed and
enable extended result code
Example:
CARRIER DCE_speed
PROTOCOL: connection_protocol
(MNP 2, 3, 4 or LAP-M)
COMPRESSION:
compression_protocol (MNP 5 or
V.42bis)
CONNECT DTE_speed (see
“Basic Result Code Options
Table”)
