8.6.4.3
GMII AC Timing Diagrams
Figure 12: GMII Output AC Timing Diagram
Figure 13: GMII Input AC Timing Diagram
GTX_CLK
TXD, TX_EN, TX_ER
VIH(min)
VIL(max)
VIH(min)
VIL(max)
tOVB
tLOW
tHIGH
tOVA
VIH(min)
VIL(max)
VIH(min)
VIL(max)
tSETUP
RX_CLK
RXD, RX_EN, RX_ER
tHOLD
tLOW
tHIGH
