88F6281
Hardware Specifications
Doc. No. MV-S104859-U0 Rev. E
Copyright © 2008 Marvell
Page 102
Document Classification: Proprietary Information
December 2, 2008, Preliminary
8.6.7.3
JTAG Interface AC Timing Diagrams
Figure 22: JTAG Interface Output Delay AC Timing Diagram
Figure 23: JTAG Interface Input AC Timing Diagram
JTCK
TDO
Tprop
(min)
Tprop
(max)
VIH
VIL
Thold
Tsetup
JTCK
TMS,TDI
