Pin and Signal Descriptions
Pin Descriptions
Copyright © 2008 Marvell
Doc. No. MV-S104859-U0 Rev. E
December 2, 2008, Preliminary
Document Classification: Proprietary Information
Page 31
MPP[32]/GE1[12]
I/O
CMOS
VDD_GE_B
RGMII Transmit Clock
RGMII transmit reference output clock for GE_TXD[3:0] and
GE_TXCTL Provides 125 MHz, 25 MHz or 2.5 MHz clock.
Not used in MII/MMII mode.
MII/MMII Carrier Sense
Indicates that the receive medium is non-idle. In half-duplex
mode, GE_CRS is also asserted during transmission. Carrier
sense is not synchronous to any clock.
GMII Carrier Sense
MPP[33]/GE1[13]
t/s
O
CMOS
VDD_GE_B
RGMII Transmit Control
Transmit control synchronous to the GE_TXCLKOUT output
rising/falling edge.
GE_TXEN is presented on the rising edge of GE_TXCLKOUT.
A logical derivative of transmit enable transmit error is presented
on the falling edge of GE_TXCLKOUT.
MII/MMII Transmit Error
It is synchronous to transmit clock.
NOTE: Multiplexed on MPP.
GMII Transmit Error
It Is synchronous to GE_TXCLKOUT.
NOTE: Multiplexed on MPP.
MPP[34]/GE1[14]
O
CMOS
VDD_GE_B
MII/MMII Transmit Enable
Indicates that the packet is being transmitted to the PHY. It Is
synchronous to transmit clock.
MPP[35]/GE1[15]
I
CMOS
VDD_GE_B
MII/MMII Receive Error
Indicates that an error symbol, a false carrier, or a carrier
extension symbol is detected on the cable. It is synchronous to
GE_RXCLK input.
NOTE: Multiplexed on MPP.
Table 8:
Gigabit Ethernet Port0/1 Interface Pin Assignments (Continued)
P i n N a m e
I / O
P i n
Ty p e
P o w e r
R a i l
D e s c r i p t i o n
