8.7
Differential Interface Electrical Characteristics
This section provides the reference clock, AC, and DC characteristics for the following differential
interfaces:
PCI Express Interface Electrical Characteristics
SATA Interface Electrical Characteristics
USB Electrical Characteristics
8.7.1
Differential Interface Reference Clock Characteristics
8.7.1.1
PCI Express Interface Differential Reference Clock Characteristics
Table 64: PCI Express Interface Differential Reference Clock Characteristics
Description
Sym bol
Min
Max
Units
Notes
Clock frequency
fCK
MHz
-
Clock duty cycle
DCrefclk
0.4
0.6
tCK
-
Differential rising/falling slew rate
SRrefclk
0.6
4.0
V/nS
3
Differential high voltage
VIHrefclk
150.0
-
mV
-
Differential low voltage
VILrefclk
-
-150.0
mV
-
Absolute crossing point voltage
Vcross
250.0
550.0
mV
1
Variation of Vcross over all rising clock edges
Vcrs_dlta
-
140.0
mV
1
Average differential clock period accuracy
Tperavg
-300.0
2800.0
ppm
-
Absolute differential clock period
Tperabs
9.8
10.2
nS
2
Differential clock cycle-to-cycle jitter
Tccjit
-
150.0
pS
-
Notes:
General Comment: The reference clock timings are based on 100 ohm test circuit.
General Comment: Refer to the PCI Express Card Electromechanical Specification, Revision 1.1,
March 2005, section 2.1.3 for more information.
1. Defined on a single-ended signal.
2. Including jitter and spread spectrum.
3. Defined from -150 mV to +150 mV on the differential w aveform.
100.0
