88F6281
Hardware Specifications
Doc. No. MV-S104859-U0 Rev. E
Copyright © 2008 Marvell
Page 94
Document Classification: Proprietary Information
December 2, 2008, Preliminary
8.6.3.2
RGMII Test Circuit
Figure 9: RGMII
Test Circuit
8.6.3.3
RGMII AC Timing Diagram
Figure 10:
RGMII AC Timing Diagram
CL
Test Point
(At Transmitter)
TX
DATA
TX
CLOCK
RX
DATA
RX
CLOCK
(At Receiver)
TskewT
TskewR
