88F6281
Hardware Specifications
Doc. No. MV-S104859-U0 Rev. E
Copyright © 2008 Marvell
Page 128
Document Classification: Proprietary Information
December 2, 2008, Preliminary
Figure 45: High Speed TX Eye Diagram Pattern Template
Figure 46: High Speed RX Eye Diagram Pattern Template
+400mV
Differential
- 400mV
Differential
0 Volts
Differential
0%
100%
+525mV
+475mV
-475mV
-525mV
7.5%
92.5%
+300mV
-300mV
37.5%
62.5%
+400mV
Differential
- 400mV
Differential
0 Volts
Differential
0%
100%
+525mV
+475mV
-475mV
-525mV
12.5%
87.5%
+175mV
-175mV
35
65
