8.6.2
SDRAM DDR2 Interface AC Timing
8.6.2.1
SDRAM DDR2 Interface AC Timing Table
Table 46: SDRAM DDR2 Interface AC Timing Table
Min
Max
Clock frequency
fCK
MHz
-
DQ and DM valid output time before DQS transition
tDOVB
0.40
-
ns
-
DQ and DM valid output time after DQS transition
tDOVA
0.40
-
ns
-
DQ and DM output pulse w idth
tDIPW
0.35
-
tCK(avg)
-
DQS output high pulse w idth
tDQSH
0.35
-
tCK(avg)
-
DQS output low pulse w idth
tDQSL
0.35
-
tCK(avg)
-
DQS falling edge to CLK-CLKn rising edge
tDSS
0.34
-
tCK(avg)
1
DQS falling edge from CLK-CLKn rising edge
tDSH
0.34
-
tCK(avg)
1
DQS latching rising transitions to associated clock edges
tDQSS
-0.11
0.11
tCK(avg)
-
DQS w rite preamble
tWPRE
0.35
-
tCK(avg)
-
DQS w rite postamble
tWPST
0.40
-
tCK(avg)
-
Average CLK-CLKn high-level w idth
tCH(avg)
0.48
0.52
tCK(avg)
1, 2, 3
Average CLK-CLKn low -level w idth
tCL(avg)
0.48
0.52
tCK(avg)
1, 2, 4
DQ input setup time relative to DQS in transition
tDSI
-0.42
-
ns
-
DQ input hold time relative to DQS in transition
tDHI
0.70
-
ns
-
Address and control output pulse w idth
tIPW
0.60
-
tCK(avg)
-
Notes:
General comment: All timing values are defined from Vref to Vref, unless otherw ise specified.
General comment: All input timing values assume minimum slew rate of 1 V/ns (slew rate defined from Vref +/-125 mV).
General comment: tCK(avg) is calculated as the average clock period across any consecutive 200 cycle w indow .
General comment: All timing parameters w ith DQS signal are defined on DQS-DQSn crossing point.
General comment: For Address and Control output timing parameters, refer to the Address Timing table.
General comment: For all signals, the load is CL = 14 pF.
1. This timing value is defined on CLK / CLKn crossing point.
2. Refer to SDRAM DDR2 clock specifications table for more information.
3. tCH(avg) is defined as the average HIGH pulse w idth, as calculated across any consecutive 200 HIGH pulses.
4. tCL(avg) is defined as the average LOW pulse w idth, as calculated across any consecutive 200 LOW pulses.
400.0
Notes
Description
Sym bol
400 MHz @ 1.8V
Units
