Page 22: Connect to the wlan web manager
3. Utilities
22
R100 Wireless Gateway
Chapter 3 - Software Configuration
Using the Wireless Gateway for the First Time
1. Wireless Gateway Utilities
Go to Start->Programs->R100 Wireless Gateway and run the Device
Discovery program .
2. Connect to the WLAN Web Manager
Click Configure when the device is found.
If your computer’s IP is not on the same subnet as the R100 Wireless
Gateway (192.168.1.X), you will be asked to change it. The IP address
can be any number from 2 to 254 that is not used by another device. The
Gateway IP address is not required.
Note: Using a proxy server for your LAN requires that you set an
exception for the R100 Wireless Gateway otherwise the connection
will fail.
Add 192.168.1.1 in the Exceptions
box if you are using a proxy server.
