Chapter 2 - Installation

2. Installation

R100 Wireless Gateway

2. Installation Procedure

Installation Procedure

Follow these steps to install the R100 Wireless Gateway.

1. Determine the best location for the wireless gateway. Keep in mind

the following considerations:
• The length of the Ethernet cable that connects the gateway to

the network must not exceed 100 metres.

• Try to place the gateway on a flat, sturdy surface as far from

the ground as possible, such as on top of a desk or bookcase,
keeping clear of obstructions and away from direct sunlight.

• Try to position the gateway in a centralised position, so that it

will provide coverage to all of the wireless mobile devices in the
area. Orientating the antenna vertically should provide the best
reception.

• Use only the power supply that came with this unit. Other power

supplies may fit but the voltage and power may not be
compatible.

2. Wall mounting or vertical standing is also possible.

3. LAN Connection: Attach one end of an RJ-45 Ethernet cable to any

one of the four LAN ports on the gateway and attach the other end to
the RJ-45 Ethernet cable to your desktop computer.

4. Power Connection: The gateway requires power from an external

power supply. The gateway ships with a UL listed, Class 2 power
supply (5V, 2A). Attach one end of the DC power adapter to the back
of the R100 and the other end to a power outlet.
The Power LED on the front of the R100 will light up when the unit is
powered ON. In addition, the blue LAN or WAN LEDs will turn ON to
indicate that the gateway has a physical Ethernet network connection.
