ANALOG CODES
CS1000 Code Scanner OB15-11
74
/#!#& # /# #! .'
/#!#& # /# #! .'
/#!#& # /# #! .'
/#!#& # /# #! .'
Model Model Years
129 1993-96
Connect wires of Scanner as follows
Scanner Data Link Connector 38-pin
Yellow Socket 31
Black Socket 1
Red Socket 3
FAULT CODE TABLE
DTC Readout Possible Cause of Failure
1 No fault found
2 IRCL control module
3 Supply pump, central locking system short to ground
4 Infrared remote control receiver, Left front door/Right front door/Trunk lid Red indicator
lamps, short to ground
5 Infrared remote control receiver, Left front door/Right front door/Trunk lid Green
indicator lamps, short to ground
6 Supply pump, central locking system, short to B (+)
7 Infrared remote control receiver, Left front door/Right front door/Trunk lid Red indicator
lamps , short to B (+) or open circuit
8 Infrared remote control receiver, Left front door/Right front door/Trunk lid Green
indicator lamps, short to B (+) or open circuit
9 Driver door switch group wiring, short to B (+) ATA/CF microswitch wiring short to B (+)
ATA/CF microswitch wiring short to B (+)
10 Ignition/starter switch-position recognition switch, open circuit
11 Ignition/starter switch-position recognition switch, open circuit 31
12 Left front door actuator, open circuit
13 Right door actuator, open circuit
14 Trunk lid lock actuator, open circuit
15 Immobilization output, short to B (+)
